PRODUCT NAME: GX II Gold 850
CODIGO: MPX-8503-AFAG-2
PEAK POWER: 850w
FORM FACTOR: ATX 12V Ver. 3.0
MODULAR: Full Modular
80 PLUS: 80 PLUS Gold
PFC: Active PFC
INPUT VOLTAGE: 100-240V
INPUT CURRENT: 10 - 5A
INPUT FREQUENCY: 50 - 60Hz
DIMENSIONES: 160 x 150 x 86mm
FAN SIZE:120mm
FAN BEARING: HDB
FAN SPEED: 2500 rpm
EFFICIENCY: = 90% @ Typical Load
ERP 2014 LOT 3: Yes
OPERATING TEMPERATURE: 0 ~ 40?
POWER GOOD SIGNAL: 100-150 ms
HOLD UP TIME: = 16ms @80%Load
MTBF: >100,000 hours
PROTECTIONS: OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge & Inrush Protection
REGULATORY: cTUVus, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (based on regions request.)
CONECTOR ATX 24 PINES: x1 = 1x (550mm)
CONECTOR EPS 4+4 PINES: x1 = 1x (600mm)
CONECTOR EPS 8 PINES: x1 = 1x (600mm)
CONECTOR SATA: x6 = 2x (500(s)+120(s)+120(s)+120(p)mm)
CONECTOR PERIPHERAL 4 PINES: x2 = 2x (500(s)+120(s)+120(s)+120(p)mm)
CONECTOR PCI-E 6+2 PINES: x4 = 2x (500+120mm)
CONECTOR 12VHPWR: x1 = 1x (650mm)
AC INPUT: 100-240V~ 10 - 5A 50 - 60Hz
